DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) - Interroll United States Sales

BRAND	Interroll
Product	DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm)
Description	motor
Internal code	ONR4178721
Technical specification	Product Name DM 0138 Asynchronous 3-Phase Degree of protection IP 69K SL Tube length 500.0 mm end face width between covers 507.0 mm EL/LW/BF installation length 530.0 mm AGL axle total length 580.0 mm Power: 370 W, winding number of pins 4 Torque [Nm] 144.0 belt tensile force 1.839 N Gear Ratio 63.00 Transmission Type Cast Iron: GGG-40 Speed at frequency 1 0.18 m/s Frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 1.01 A Rated current, low voltage 1.74 A Speed at frequency 2 0.22 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Tube diameter A 156.6 mm pipe diameter B 156.6 mm Pipe shape profiled Tube Option Type UNI Series MPB Number of teeth 10 Coating material NBR rubber coating hardness 70 Shore A Coating paint white coating process hot vulcanized Cover A Standard Cover B Standard Standard Lid A Material Stainless Steel: 1.4305/303 Lid B Stainless Steel Material: 1.4305/303 Shaft A version Replacement 138i Standard Shaft B Replacement Design 138i Standard Shaft A Material Stainless Steel: 1.4305/303 Shaft B Material Stainless Steel: 1.4305/303 Shaft A Diameter 30.0 mm Shaft B Diameter 30.0 mm Wave A wrench width 20.0 mm Shaft B spanner width 20.0 mm Wave A key area length 25.0 mm shaft B spanner length 25.0 mm Oil type synthetic food oil Electrical connection terminal box Elek. Connection material stainless steel: 1.4301/304

Please Contact Us to Order to offer best price and delivery time for Interroll - DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) by Interroll in United States?

You can purchase DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DM 0138 (MI-DM0138 DM1383-A7E13B0E5MAA-507mm)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
