| BRAND | R.Stahl |
| Product | P/N: 220903, Type: 6001/542-9510-15-131 |
| Description | Linear luminaire for fluorescent lamps |
| Internal code | ONR3313889 |
| Weight | 6.75 |
| Custom code | 94054940 |
| Technical specification | GRP explosion-proof Tipo: 6001/542-9510-15-131 Light tray: clear Tub material: polycarbonate Case material: polyester resin Design: standard version Housing colour: light grey (RAL 7035) Range of use (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex db eb IIC T4 Gb Dust explosion protection: II 2 D Ex tb IIIC T80 °C Db Number of lamps: 2 Light power: 36 W LED lifespan: - Maximum solid wire connection: 6 mm2 Flexible connection max.: 4 mm2 Dimensions (L x W x H): 1310 x 184 x 125 mm Rated operating voltage AC: 220.00 - 240.00 V Rated operating voltage DC: 220.00 - 240.00 V Minimum ambient temperature: -30 °C Maximum ambient temperature: +50 °C Note through wiring: max. 3 x 16 A Maximum ambient temperature.2: +55 °C Note through wiring 2: max. 3 x 10 A Impact resistance (IEC 62262): IK10 Through-wiring: with 5 2.5 mm2 conductors Ballast: 6042/243-21 Thread plate: 2x plastic Holes: 3 x M25 settled Cable and cable entries: 2 x M25 Ø 7 — 17 mm Cable entry material: black polyamide Sealing plug: 2 x M25 x 1.5 Sealing plug material: black polyamide Terminal block installed: PE + N + L1 + L2 + L3 Documentation languages: German English Sign languages: German English French For more information, see: r-stahl.com Webcode 6001A Longfield lamp for fluorescent lamps explosion-proof Case material: polyester resin Tub material: polycarbonate Number of lamps: 2 Light power: 36 W Dimensions (L x W x H): 1310 x 184 x 125 mm Rated operating voltage AC: 220.00 - 240.00 V Rated operating voltage DC: 220.00 - 240.00 V Range of use (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex de IIC T4 Gb Dust explosion protection: II 2 D Ex tb IIIC 80 °C Db Min. ambient temperature: -30 °C Max. ambient temperature: +55 °C Protection class (IP): IP66 Through-wiring: with 5 conductors Thread plate: - Holes: 3 x M25 Accessories: included Screw connections: 2 x M25 Ø 7 — 17 mm Cable entry material: black polyamide Sealing plug: 2 x M25 x 1.5 Sealing plug material: black polyamide For more information, see: www.stahl.de Webcode 6001A Manufacturer name: R. STAHL Schaltgeräte GmbH Type: 6001/542-9510-15-131 !! Delivery of the item is only possible until the end of April!! |
Please Contact Us to Order to offer best price and delivery time for Stahl - P/N: 220903, Type: 6001/542-9510-15-131 Linear luminaire for fluorescent lamps number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Stahl - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy P/N: 220903, Type: 6001/542-9510-15-131 by Stahl in United States?
You can purchase P/N: 220903, Type: 6001/542-9510-15-131 by Stahl from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the P/N: 220903, Type: 6001/542-9510-15-131?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stahl in United States?
While we are not the official distributor or seller of Stahl in United States, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.
How can I access P/N: 220903, Type: 6001/542-9510-15-131 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for P/N: 220903, Type: 6001/542-9510-15-131 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for P/N: 220903, Type: 6001/542-9510-15-131?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
