| BRAND | Stahl |
| Product | 8570/11-306-B-04-0-00-XXX / 289533 |
| Description | 16 A wall socket |
| Internal code | ONR5067952 |
| Custom code | 85366990 |
| Technical specification | explosion-proof 8570/11-3.. -B Detailed number of poles: 2P + PE (1P + N + PE) Coding (time setting): 99 Housing material: polyamide, glass-reinforced Silicone-free: Yes Range of application (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6... T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T73 °C Db Min. ambient temperature: -40 °C Max. ambient temperature: +45 °C Rated operation current: 16 A Min.2 ambient temperature: -40 °C Max. ambient temperature.2: +65 °C Rated operating current2:10 A Ambient temperature min. F: -40 °F Ambient temperature max. F: +113 °F Ambient temperature min. °F 2: -40 °F Ambient temperature max. °F 2: +149 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP64 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Introduction of 1 clamp.: 0 mm Technical data: This product is silicone-free Gas - explosion protection: Ex II 2 G Ex db eb IIC T6... T5 Gb Dust - explosion protection: Ex II 2 D Ex tb IIIC T73°C Db Test certificate: PTB 03 ATEX 1227, IECEx PTB 05.0023, Rated operating current: 10... 16 A Rated voltage: 200... 250V AC Rated frequency [Fn]: 50/60Hz Number of poles: 2P+PE Code color: blue Safety contact position: 6h Ambient temperature: -40 °C < Ta < 45 °C... 65 °C Protection class: IP66 Auxiliary contact: - Introductions: Position 1:8161/7-M20-1304 with reduction to M20 Position 2:8290/3-M20 with reduction to M20 |
Please Contact Us to Order to offer best price and delivery time for Stahl - 8570/11-306-B-04-0-00-XXX / 289533 16 A wall socket number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Stahl - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 8570/11-306-B-04-0-00-XXX / 289533 by Stahl in United States?
You can purchase 8570/11-306-B-04-0-00-XXX / 289533 by Stahl from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 8570/11-306-B-04-0-00-XXX / 289533?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stahl in United States?
While we are not the official distributor or seller of Stahl in United States, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.
How can I access 8570/11-306-B-04-0-00-XXX / 289533 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 8570/11-306-B-04-0-00-XXX / 289533 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 8570/11-306-B-04-0-00-XXX / 289533?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
