DM0803-AAA01A0E0HJE-309mm - Interroll United States Sales

BRAND	Interroll
Product	DM0803-AAA01A0E0HJE-309mm
Internal code	ONR5060528
Technical specification	MI-DM0080 Product name DM 0080 3-phase asynchronous Protection level IP 69K Tube length (SL) 302.0 mm Drum width (FW) 309.0 mm Installation length (EL/LW/BF) 314.0 mm Overall axle length (AGL) 339.0 mm Power 140 W coil number of pins 2 Torque [Nm] 13.8 Band tensile force 339 N Gear ratio (i) 31.35 Gear material name Steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.38 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.38 A rated current, low voltage 0.65 A Speed at frequency 2 0.47 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel pipe material: St37-2/AISI 1015 Pipe diameter (A) 81.5 mm Pipe diameter (B) 80.5 mm Convex tube shape (standard) Cover A version Standard cover B version Standard Cover A Material ALUMINUM: EN-AC43400/AL239 Cover B Material ALUMINUM: EN-AC43400/AL239 Shaft A version standard Ø17mm shaft B version standard Ø17mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A key area (F) 13.5 mm Wave B key area (F) 13.5 mm Wave A key face length (C) 12.5 mm Wave B key face length (C) 12.5 mm Oil type mineral oil viscosity 68 Electrical connection straight screw connection Elek. Connection material brass CuZn39pb3/MS58 Power cable length 10.0 m Power cable type unshielded; not halogen-free min. ambient temperature 2 °C max. ambient temperature 40 °C

Please Contact Us to Order to offer best price and delivery time for Interroll - DM0803-AAA01A0E0HJE-309mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy DM0803-AAA01A0E0HJE-309mm by Interroll in United States?

You can purchase DM0803-AAA01A0E0HJE-309mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the DM0803-AAA01A0E0HJE-309mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access DM0803-AAA01A0E0HJE-309mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DM0803-AAA01A0E0HJE-309mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DM0803-AAA01A0E0HJE-309mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
