| BRAND | Schenck |
| Product | V133971.B01 |
| Description | Belt speedometer |
| Internal code | ONR274110 |
| Weight | 4.55 |
| Custom code | 9029 90 00 |
| Technical specification | PDE Part Number = F020401.01 Belt tacho FGA 20 RSLE execution in zinc Belt speedometer FGA 20 - RSLE complete with bracket and friction wheel Drawing F010840.01.Belt speedometer with friction wheel according to drawing information and sample from 11/96 and sealing sample from 12/02 from Preuss or sample from 09/07 from Hilse manufactured and assembled including all attachement and assembly parts Details of implementation: -Device made of mild steel St52-3/DIN 1.0570, all steel parts galvanized blue galvanized or comparable corrosion resistance components. -lasered wheel with a machine manufactured rim base. Rim base diameter 177, outer diameter 185mm -wheel rubber O-Ring Mat.4217569 glued with silicon or superglue at 4 points on circumfence to the wheel. -Machined hub with tension-free, sealed deep groove ball bearings for smooth running of the friction wheel. -Wheel and hub pressed and glued, concentricity / axial runout max. 1mm absolute. (LOCTITE 638) -Hub waterproof sealed on one-side with Kapsto cap. Axle sealed with NILOS LSTO sealing ring. Please pay attention to smooth running! -Swing arm mounting designed with bronze metal bearing bushing, axis guided without play but nevertheless smoothly, axially secured with washers and split pin. -Bar with loosely screwed fasteners according to parts list -Proximity switch Mat.3732054 inserted into the rocker arm and set and fixed to a switching distance of 3-4mm, taking into account the axial run-out deviation of the wheel. - Equipped with nameplate: individually packed in a suitable corrugated cardboard box and marked with the material number. Attention: Change 617659: new switch IFM type and design see CSD Sto.Nr.37320 54 |
Please Contact Us to Order to offer best price and delivery time for Schenck - V133971.B01 Belt speedometer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Schenck - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy V133971.B01 by Schenck in United States?
You can purchase V133971.B01 by Schenck from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the V133971.B01?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Schenck in United States?
While we are not the official distributor or seller of Schenck in United States, we source our products from reliable channels and offer you original Schenck equipment at competitive prices.
How can I access V133971.B01 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for V133971.B01 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for V133971.B01?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
