MI-DL0113 DL1131-BAA0AD0SDKSC-959mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DL0113 DL1131-BAA0AD0SDKSC-959mm
Internal code	ONR4997695
Technical specification	Product Name DL 0113 Asynchronous 1-Phase Certification cRUus UL Certified IP Rating 66 Shell Length (SL) 36.890 " Face Width (FW) 37.76 " Between Frames (EL/LW/BF) 37.99 " Overall Length (AGL) 39.57 " Poles 4 Power 0.20 hp Torque [Nm] 33.7 Belt Pull Force 595 N Gear Ratio (i) 44.09 Velocity at Frequency 1 41 fpm Frequency 1 60 Hz External Wiring Diagram 113ED-55 High Voltage 115 V Current, High Voltage 3.01 A Velocity at Frequency 2 34 fpm Frequency 2 50 Hz High Voltage 2 230 V Low Voltage 2 0 V Shell Material Steel: St37-2 / AISI 1015 Shell Diameter (A) 4.46 " Shell Diameter (B) 4.42 " Shell Shape Crowned (Standard) Housing A Material ALU: EN-AC44300 / AL230 Housing B Material ALU: EN-AC44300 / AL230 Shaftcap A Material Aluminium Shaftcap B Material Aluminium Shaftcap A Diameter 1.38 " Shaftcap B Diameter 1.38 " Shaftcap A Flat Width 0.83 " Shaftcap B Flat Width 0.83 " Shaftcap A Flat Length 0.79 " Shaftcap B Flat Length 0.79 " Oil Type Mineral Oil Electrical Connection Shaft Cap with Slot Power Cable Length 3.0 m Power Cable Type

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DL0113 DL1131-BAA0AD0SDKSC-959mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
