MI-DL0113 DL1133-AACABE0G1JDC-512mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DL0113 DL1133-AACABE0G1JDC-512mm
Internal code	ONR5039840
Technical specification	Product Name DL 0113 Asynchronous 3-Phase Certification cRUus UL Certified IP Rating 66 Shell Length (SL) 19.291 " Face Width (FW) 20.16 " Between Frames (EL/LW/BF) 20.39 " Overall Length (AGL) 21.97 " Poles 4 Power 0.24 hp Torque [Nm] 34.7 Belt Pull Force 612 N Gear Ratio (i) 38.51 Velocity at Frequency 1 49 fpm Frequency 1 60 Hz External Wiring Diagram E33 High Voltage 460 V Current, High Voltage 0.65 A Velocity at Frequency 2 41 fpm Frequency 2 50 Hz High Voltage 2 400 V Low Voltage 2 0 V Shell Material Stainl. Steel: 1.4301 / 304 Shell Diameter (A) 4.46 " Shell Diameter (B) 4.42 " Shell Shape Crowned (Standard) Housing A Material Stain.Steel: 1.4301/304 Housing B Material Stain.Steel: 1.4301/304 Shaftcap A Material Stainl. Steel: 1.4336 / 316 Shaftcap B Material Stainl. Steel: 1.4336 / 316 Shaftcap A Feature 60° Grease Nipple Pla Shaftcap B Feature 60° Grease Nipple Pla Shaftcap A Diameter 1.38 " Shaftcap B Diameter 1.38 " Shaftcap A Flat Width 0.83 " Shaftcap B Flat Width 0.83 " Shaftcap A Flat Length 0.79 " Shaftcap B Flat Length 0.79 " Oil Type Food Grade Synthetic Oil Viscosity 68 Electrical Connection Shaft Cap without Slot Power Cable Length 3.0 m Power Cable Type Non Screened; Non Halogen Free Min Ambient Temperature -25 °C Max Ambient Temperature 40 °C

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DL0113 DL1133-AACABE0G1JDC-512mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MI-DL0113 DL1133-AACABE0G1JDC-512mm by Interroll in United States?

You can purchase MI-DL0113 DL1133-AACABE0G1JDC-512mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MI-DL0113 DL1133-AACABE0G1JDC-512mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DL0113 DL1133-AACABE0G1JDC-512mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DL0113 DL1133-AACABE0G1JDC-512mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DL0113 DL1133-AACABE0G1JDC-512mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
