MI-DM0080 DM0803-AAA0BA0E0KJC-294mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DM0080 DM0803-AAA0BA0E0KJC-294mm
Internal code	ONR5067152
Technical specification	IP class 69K Length (SL) 287.0 mm Dimension (FW) 294.0 mm Dimension (EL/LW/BF) 299.0 mm Dimension (AGL) 324.0 mm Power 140 W Number of poles 2 Torque [Nm] 18.6 Traction force 458 N Reduction ratio (i) 42.28 Reducer Material Steel: 16MnCr5/AISI 5115 Nominal speed 0.28 m/s Nominal frequency 50 Hz M34 external wiring diagram Nominal voltage: high: 400 V; nominal voltage: low: 230 V Current High voltage 0.38 A Current nominal low voltage 0.65 A Speed Frequency 2 0.35 m/s Frequency 2 60 Hz High nominal voltage 2460 V Nominal low voltage 2 230 V Tube material: Steel External dimension (A) 81.5 mm External dimension (B) 80.5 mm Tube shape: Standard domed End flange (A) Standard End flange (B) Standard Flanged Material (A) ALU: EN-AC43400/AL239 Flanged Material (B) ALU: EN-AC43400/AL239 Shape axis (A) standard Ø30mm Shape axis (B) standard Ø30mm Shaft Material (A) 303 Stainless Steel Shaft Material (B) 303 Stainless Steel A (F) axis flat width 25.0 mm B axis flat width (F) 25.0 mm A (C) axis flat length 12.5 mm B axis flat length (C) 12.5 mm Type of lubricant Mineral Oil Viscosity 68 Elec. connector straight connection Material signal connection Brass Power cable length 3.0 m Power cable type: Unshielded Ambient temperature min. 2 °C Ambient temperature max. 40 °C EQUIVALENT TO 13664727

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0080 DM0803-AAA0BA0E0KJC-294mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MI-DM0080 DM0803-AAA0BA0E0KJC-294mm by Interroll in United States?

You can purchase MI-DM0080 DM0803-AAA0BA0E0KJC-294mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MI-DM0080 DM0803-AAA0BA0E0KJC-294mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0080 DM0803-AAA0BA0E0KJC-294mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0080 DM0803-AAA0BA0E0KJC-294mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0080 DM0803-AAA0BA0E0KJC-294mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
