MI-DM0113 DM1133-AEB0VA0E9TBB-557mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DM0113 DM1133-AEB0VA0E9TBB-557mm
Description	motor
Internal code	ONR4875864
Technical specification	Product name DM 0113 3-phase asynchronous Protection level IP 69K Tube length (SL) 550.0 mm Installation length (EL/LW/BF) 570.0 mm Drum width (FW) 557.0 mm Total axle length (AGL) 620.0 mm Power 160 W Torque [Nm] 157.5 Gear ratio (i) 168.00 Speed at frequency 1 0.05 m/s Frequency 1 50 Hz high voltage 400 V Rated current, high voltage 0.54 A Speed at frequency 2 0.06 m/ Frequency 2 60 Hz high voltage 2 460 V Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 121.5 mm Spherical pipe shape (standard) Pipe option type smooth rubber coating Coating material NBR rubber coating Coating color black Cover A standard version Cover A material ALU: EN-AC43400/AL239 Shaft A standard version with Ø25mm option Wave A material stainless steel: 1.4305/303 Wave A key area (F) 20.0 mm Wave A key area length (C) 25.0 mm Shaft A tension thread (X) M8 Shaft A tension thread position 12.50 mm Oil type mineral oil Electrical connection angle screw Power cable length 1.0 m Pin number 4 winding Strap tensile force 2,592 N Transmission Material description Cast-iron: GGG-40 external connection diagram M34 low voltage 230 V Rated current, low voltage 0.94 A low voltage 2 230 V Pipe diameter (B) 120.0 mm Coating hardness 65 Shore A Cold glued coating process Cover B version standard Cover B material ALU: EN-AC43400/AL239 Shaft B version standard Ø25mm Shaft B material stainless steel: 1.4305/303 Wave B key area (F) 20.0 mm Wave B key area length (C) 25.0 mm Elec. Connection material stainless steel: 1.4305/303 Power cable type unshielded; not halogen-free

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0113 DM1133-AEB0VA0E9TBB-557mm motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MI-DM0113 DM1133-AEB0VA0E9TBB-557mm by Interroll in United States?

You can purchase MI-DM0113 DM1133-AEB0VA0E9TBB-557mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MI-DM0113 DM1133-AEB0VA0E9TBB-557mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0113 DM1133-AEB0VA0E9TBB-557mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0113 DM1133-AEB0VA0E9TBB-557mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0113 DM1133-AEB0VA0E9TBB-557mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
