MI-DM0138 DM1383-AAA03A0E5JFA-1057mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DM0138 DM1383-AAA03A0E5JFA-1057mm
Internal code	ONR4947082
Technical specification	Product name DM 0138 3-phase asynchronous Protection level IP 69K Tube length (SL) 1,050,0 mm Drum width (FW) 1,057,0 mm Installation length (EL/LW/BF) 1,080.0 mm Overall axle length (AGL) 1,130.0 mm Power 370 W Winding number of poles 4 Torque [Nm] 68.6 Band tensile force 994 N Gear ratio (i) 30.00 Transmission Material description Cast iron: GGG-40 Speed at frequency 1 0.33 m/s Frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 1.01 A rated current, low voltage 1.74 A Speed at frequency 2 0.41 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 138.0 mm Tube diameter (B) 136.0 mm Convex tube shape (standard) Cover A version Standard cover B version Standard Cover A Material ALUMINUM: EN-AC43400/AL239 Cover B Material ALUMINUM: EN-AC43400/AL239 Shaft A version replacement 138i standard shaft B version replacement 138i standard Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Shaft A diameter (D) 30.0 mm Shaft B diameter (D) 30.0 mm Wave A key area (F) 20.0 mm Wave B key area (F) 20.0 mm Wave A key face length (C) 25.0 mm Wave B key face length (C) 25.0 mm Oil type mineral oil Electrical connection terminal box Elek. Connection material polyamide 6 + glass fiber

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0138 DM1383-AAA03A0E5JFA-1057mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
