BRAND | Interroll |
Product | MI-DM0138 DM1383-BAA0+70G5ECH-607mm |
Internal code | ONR4891146 |
Technical specification | Product Name DM 0138 Asynchronous 3-Phase Certification cRUus UL & UKCA Certified IP Rating 69K Shell Length (SL) 23.62 " Face Width (FW) 23.90 " Between Frames (EL/LW/BF) 24.65 " Overall Length (AGL) 26.93 " Poles 4 Power 0.50 hp Torque [Nm] 29.7 Belt Pull Force 430 N Gear Ratio (i) 16.00 Gear Material Casted Steel: GGG-40 Velocity at Frequency 1 152 fpm Frequency 1 60 Hz External Wiring Diagram M31 High Voltage 460 V Current, High Voltage 0.86 A Velocity at Frequency 2 124 fpm Frequency 2 50 Hz High Voltage 2 400 V Low Voltage 2 0 V Shell Material Steel: St37-2 / AISI 1015 Shell Diameter (A) 5.43 " Shell Diameter (B) 5.35 " Shell Shape Crowned (Standard) Housing A Feature Standard Housing B Feature Standard Housing A Material ALU: EN-AC43400 / AL239 Housing B Material ALU: EN-AC43400 / AL239 Shaft A Shape Special Shaft 1 flat Ø30mm Shaft B Shape Special Shaft 1 flat Ø30mm Shaft A Material Stainl. Steel: 1.4305 / 303 Shaft B Material Stainl. Steel: 1.4305 / 303 Shaft A Diameter (D) 1.18 " Shaft B Diameter (D) 1.18 " Shaft A Flat Width (F) 0.79 " Shaft B Flat Width (F) 0.79 " Shaft A Flat Length (C) 1.14 " Shaft B Flat Length (C) 1.14 " Oil Type Food Grade Synthetic Oil Electrical Connection Shaft Slot Power Cable Length 3.0 m Power Cable Type |
Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0138 DM1383-BAA0+70G5ECH-607mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy MI-DM0138 DM1383-BAA0+70G5ECH-607mm by Interroll in United States?
You can purchase MI-DM0138 DM1383-BAA0+70G5ECH-607mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the MI-DM0138 DM1383-BAA0+70G5ECH-607mm?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Interroll in United States?
While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.
How can I access MI-DM0138 DM1383-BAA0+70G5ECH-607mm catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for MI-DM0138 DM1383-BAA0+70G5ECH-607mm on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for MI-DM0138 DM1383-BAA0+70G5ECH-607mm?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
Conveyor roller
