| BRAND | Interroll |
| Product | MI-DMI AC138I-LCD0AA0E6LGA-600m |
| Description | drum motor |
| Internal code | ONR346435 |
| Weight | 21.7 |
| Technical specification | Product name 138i drum motor Protection grade IP 66 SL tube length 600.0 mm end face width between covers 613.0 mm EL/LW/BF installation length 630.0 mm AGL axle total length 680.0 mm Power 370 W number of winding pins 4 Torque [Nm] 123.0 Tension force 1,663 N Gear ratio 49.64 Speed at frequency 1 0.209 m/s Frequency 1 50 Hz winding number of phases 3 high voltage 400 V low voltage 230 V Speed at frequency 2 0.251 m/s Frequency 2 60 Hz low voltage 2 276 V largest outer diameter 148.0 mm Convex tube shape (standard) Steel pipe material: St37-2/AISI 1015 Tube option type smooth rubber coating Coating material NBR rubber coating coating hardness 65 Shore A Coating color black coating process hot vulcanized Plating thickness 5.0 mm Standard cover Cover material ALU AlSi10Mg (Fe)/AL239 Sealing material/Labyrinth steel Standard shaft design Shaft material steel: 11SMnPb30/AISI Shaft diameter 30.0 mm Wave key area 20.0 mm Wave key surface length 25.0 mm Oil type mineral oil viscosity 150 Electrical connection side A side Elec. Connection type terminal box Elek. Connection material ALU AlSi10Mg (Fe)/AL239 |
Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DMI AC138I-LCD0AA0E6LGA-600m drum motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy MI-DMI AC138I-LCD0AA0E6LGA-600m by Interroll in United States?
You can purchase MI-DMI AC138I-LCD0AA0E6LGA-600m by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the MI-DMI AC138I-LCD0AA0E6LGA-600m?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Interroll in United States?
While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.
How can I access MI-DMI AC138I-LCD0AA0E6LGA-600m catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for MI-DMI AC138I-LCD0AA0E6LGA-600m on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for MI-DMI AC138I-LCD0AA0E6LGA-600m?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
