Oti Dali 50/220-240/1A4 Lt2 L G2 - Osram United States Sales

Q: Where can I buy Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram in United States?

You can purchase Oti Dali 50/220-240/1A4 Lt2 L G2 by Osram from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

Q: What is the price of the Oti Dali 50/220-240/1A4 Lt2 L G2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Q: Who is the official distributor or seller of Osram in United States?

While we are not the official distributor or seller of Osram in United States, we source our products from reliable channels and offer you original Osram equipment at competitive prices.

Q: How can I access Oti Dali 50/220-240/1A4 Lt2 L G2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Oti Dali 50/220-240/1A4 Lt2 L G2 on our website. Visit our resources section or contact us directly for specific documents.

Q: Do you provide technical support for Oti Dali 50/220-240/1A4 Lt2 L G2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND	Osram
Product	Oti Dali 50/220-240/1A4 Lt2 L G2
Description	Led Driver
Internal code	ONR5123218
Technical specification	Electrical data: Nominal input voltage: 220…240 V Mains frequency: 0/50/60 Hz Input voltage AC: 198…264 V Input voltage DC: 176…276 V Current set: DALI / LEDset / Programmable Total harmonic distortion: < 15 % Power factor λ: > 0.95 Efficiency in full-load: 90 % Device power loss: 6.0 W Networked standby power: ≤ 0.17 W Protective conductor current: <0.5 mA Inrush current: 20 A Max. ECG no. on circuit breaker 10 A (B) : 13 Max. ECG no. on circuit breaker 16 A (B) : 20 Max. ECG no. on circuit breaker 25 A (B) : - Surge capability (L/N-Ground) : 2 kV Surge capability (L-N) : 1 kV Nominal output voltage: 15…54 V U-OUT (working voltage) : < 60 V Nominal output current: 600…1400 mA Output current LEDset open: 300 mA Output current LEDset shorted: 1400 mA Default output current: 300 mA Output current tolerance: ±3 % Output ripple current (100 Hz) : < 1 % Output PSTLM: ≤1 Output SVM: ≤0.4 Nominal output power: 12…50 W Maximum output power: 50 W Galvanic isolation: SELV Dimensions & weight: Mounting hole spacing, length: 350.0 mm Product weight: 240.00 g Cable cross-section, input side: 0.5…1.5 mm² Cable cross-section, output side: 0.5…1.5 mm² Wire preparation length, input side: 8.0…9.0 mm Wire preparation length, output side: 8.0…9.0 mm Length: 360.0 mm Height: 21.0 mm Width: 30.0 mm Colors & materials: Casing material: Metal Temperatures & operating conditions: Ambient temperature range: -25…+50 °C Maximum temperature at tc test point: 75 °C Max.housing temperature in case of fault: 110 °C Temperature range at storage: -40…+85 °C Permitted rel. humidity during operation: 5…85 % Lifespan: ECG lifetime: 50000 / 100000 h Additional product data: Encapsulated: No Predecessor EAN: 4052899028098 Capabilities: Programming interface: DALI, LEDset Dimmable: Yes Dimming interface: DALI-2 / Touch DIM / Touch DIM Sensor Dimming range: 1…100 % Dimming method: Amplitude Modulation Constant lumen function: Programmable Overheating protection: Automatic reversible Overload protection: Non-reversible Short-circuit protection: Automatic reversible No-load proof: Yes Intended for no-load operation: No Max. cable length to lamp/LED module: 2.0 m Suitable for fixtures with prot. class: I Suitable for emergency lighting: Yes Type of connection, input side: Push terminal Type of connection, output side: Push terminal DALI-2 Diagnostic Data: Yes Number of channels: 1 Control interface: DALI DALI-2 Energy Data: Yes Programming: Programming device: DALI magic Tuner4TRONIC: Yes Tuner4TRONIC Field App: Yes Programmable features Operating Current: Yes Constant Lumen: Yes Lamp Operating Time: Yes Driver Guard: Yes DALI Settings: Yes Emergency Mode: Yes DALI-2 Luminaire Data: Yes Soft Switch Off: Yes Dim to Dark: Yes TouchDIM + Sensor: Yes Corridor Functionality: Yes OEM Key: Yes Certificates & standards: Approval marks – approval: CE / EL / VDE-ENEC / VDE-EMC / EAC / CCC / RCM / BIS Standards: Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 62386 Type of protection: IP20

Please Contact Us to Order to offer best price and delivery time for Osram - Oti Dali 50/220-240/1A4 Lt2 L G2 Led Driver number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Osram - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
