MI-DM0080 DM0803-C++01B0E0JHK-300mm - Interroll United States Sales

BRAND	Interroll
Product	MI-DM0080 DM0803-C++01B0E0JHK-300mm
Internal code	ONR5061348
Technical specification	IP class 69K Length (SL) 293.0 mm Dimension (FW) 300.0 mm Dimension (EL/LW/BF) 305.0 mm Dimension (AGL) 330.0 mm Power 140 W Number of poles 2 Torque [Nm] 17.0 Traction force 399 N Reduction ratio (i) 38.50 Reducer Material Steel: 16MnCr5/AISI 5115 Nominal speed 0.32 m/s Nominal frequency 50 Hz M34 external wiring diagram Nominal voltage: high: 400 V; nominal voltage: low: 230 V Current High voltage 0.38 A Current nominal low voltage 0.65 A Speed Frequency 2 0.40 m/s Frequency 2 60 Hz High nominal voltage 2460 V Nominal low voltage 2 230 V Tube Material: 304 Stainless Steel External dimension (A) 85.0 mm External dimension (B) 81.0 mm Tube shape: 2 x Standard Crowned Tube option: Smooth coating Lining Material: Rubber, NBR, Lining Hardness: 70 Shore A Coating color White Hot vulcanization type End flange (A) Standard End flange (B) Standard Flanged Material (A) ALU: EN-AC43400/AL239 Flanged Material (B) ALU: EN-AC43400/AL239 Shaft shape (A) standard Ø17mm Shaft shape (B) standard Ø17mm Shaft Material (A) 303 Stainless Steel Shaft Material (B) 303 Stainless Steel A (F) axis flat width 13.5 mm B axis flat width (F) 13.5 mm A (C) axis flat length 12.5 mm B axis flat length (C) 12.5 mm Type of lubricant Synthetic-Food Oil Viscosity 68 Elec. angled connector Material PBT signal connection Power cable length: 10.0 m. Power cable type: Shielded Ambient temperature min. -25 °C Ambient temperature max. 40 °C

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0080 DM0803-C++01B0E0JHK-300mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
