129475/ 0.5.456.425 - Sauter United States Sales

BRAND	Sauter
Product	129475/ 0.5.456.425
Description	12-way tool disk revolver
Internal code	ONR5055687
Technical specification	Spare revolver for # 001200620: For installation on Gamma V3 lathe below 45 degrees to the horizontal Gildemeister ID no.: 2550237 Laser into the nameplate with axial tool drive --------------- according to drawing 0.5.456.425-AZ11 consisting of: 126577 SAUTER 12-way tool disc revolver 0.5.461.425 prepared to install a axial tool drive Right version nominal height 180 mm Engine layout: backwards Bidirectional direction of rotation Hydraulic turret lock Directional valve installed by the customer for this purpose operating pressure 50 bar allowable mass moment of inertia of 16 kgm2 Installation and function: according to electr. Wiring diagram EPB-1151 in accordance with the HP-497 hydraulic diagram according to function diagram SK-1489 Tool revolver is being prepared for mounting Siemens 1 FT7 105-5AF71 1 ST 113821 coupling 1.5.450.017 for the installation of AC servomotor type SIEMENS 1 FT7 105... 1 ST 131082 ACCESSORY 1.5.450.090; Special revolver mount Gamma V3 1 ST 131148 final assembly parts; screw connections Hydr. Tube diameter 18 mm 1 ST 131123 FINAL ASSEMBLY PARTS (KSS pipe) Gamma V3 1 ST 112988 distributor 1.5.450.089 (arrangement above) metric, incl. socket (16-pin) 1 ST 113842 locking parts 1.5.461.561 1 ST 129476 tool drive 0.0.076.425 for driven tools according to drawing 0.0.076.425-ZP01 Individual drive via gears with clutch Working position: x = +240 mm y = 0 mm That means center of the axis and right Gear ratio i = 1 The coupling position is controlled by 1 electronic check the limit switch; switchable by means of hydraulic cylinders Installation and function: in accordance with the circuit diagram EPB-1151 and according to function diagram SK-1489 1 ST 113672 sliding coupling 1.0.076.016 with Coupling profile W 24x1.25 DIN 5480 -------------- associated spindle heads 0.5.941.05 in accordance with PI 29.3 1 ST 113709 coolant valve 5-25 bar Pipe connection outer diameter 15 mm Supply to the tool wheel in position R 264; 345 degrees 1 ST 129489 final assembly parts (pipes) 1.0.076.091 Performance data on the tool coupling nmax.: 4000 rpm, M: engine-dependent Capacity: 100 Nm 1 ST 105397 2nd type plate Revolver 1.5.480.095 (Attach loosely to the revolver in the pouch!) without tool disc without AC servomotor without AC servomotor control without directional valve Gildemeister ID: 2550237 Laser into the type plate of the disc 1 ST 130648 SAUTER 12-fold tool disc 0.5.901.025/456 to accommodate tool holders after DIN 69 880 T1 Outer disc diameter: 597 mm disc thickness 93 mm Mounting holes for shaft diameter 50 mm on dividing circle diameter TK: 480mm (for powered tools and for standard tools) (working position X = +240; Y = 0) 6 additional around the circumference of the disc Recordings arranged in pos. 1,3,5,7,9 + 11 for boring bar holders Wrench size 580 mm Right version Position No. episode left-sinnig 1, 2,... No. 1 at 3:00 Coolant supply 5 - 25 bar in position: R 264 mm; 345 degrees Burnished surface including clamping elements 1 ST 068733 accessories (pens) 1.5.901.090 12 ST 114573 sealing plugs DIN 69 880 form Z2 D = 50mm 50 S with O-ring (12 pieces/slice included in the base price) Painting: RAL 7016 anthracite grey

Please Contact Us to Order to offer best price and delivery time for Sauter - 129475/ 0.5.456.425 12-way tool disk revolver number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
