118004 / Typ:0.5.450.416 - Sauter United States Sales

BRAND	Sauter
Product	118004 / Typ:0.5.450.416
Description	12-way tool disk revolver
Internal code	ONR5055684
Technical specification	spare revolver Revolver type: 0.5.450.416 Comm. -No.:10.23431/1 ID NO.: 118004 0.5.450.416 for powered tools Engine layout: backwards according to drawing 0.5.450.416-AZ11 Right version L-shaped housing nominal height 100 mm Direction of rotation: bidirectional revolver rotary drive and tool drive with AC servomotor Installation and function: according to circuit diagram EP-1150 SK-1487 functional diagram and HP-496 hydraulic diagram Hydraulic turret lock operating pressure 50 bar allowable mass moment of inertia: 2.5 kgm2 self-locking overload clutch With el. Slewing drive monitoring of the revolver Turret and tool drive Is being prepared to grow a AC servo motors The servomotor is fitted by the lathe manufacturer. 2 1 ST 115412 coolant system, 5-25 bar steel version 1.5.450.509 Coolant supply to the tool wheel in position R 95 mm; at 345 degrees 1 ST 115451 coupling for mounting Lenze MDSKAIG 090 servomotor 1 ST 078041 accessories (revolver mounted on intermediate plate) 5 1 ST 112370 Electrical distributor 1.5.450.089 (metric screw connections) rear arrangement, vertical, accessible from outside Coupling for tool drive in pos. 3:00 a.m. 6 1 ST 114965 sliding coupling 1.5.450.016 for tool disc SW 320 mm Coupling profile in accordance with DIN 5480-N16x0.8 max. power on the tool: n max. = 5000 rpm, T max. = 32 Nm at S3 = 40% ED 1 ST 119222 Hydraulic final assembly parts + coolant net price without AC servomotor without directional valve 1 ST 112445 SAUTER 12-fold tool disc 0.5.901.016/450 to pick up tool holders after DIN 69 880 T1 in a radial arrangement Wrench size 270 mm Mounting holes for shaft diameter 30 mm Right version Position number left-handed sequence 1,2,... No. 1 at 3:00 a.m. with rev. version “right” Coolant pressure system 5 - 25 bar Coolant supply in position R 95 mm; 345 degrees for “right” version Surface not burnished 1 ST 122057 final assembly parts at 450. 1 ST 115379 closing plate The above net price includes clamping elements Painting: RAL 7035 - light grey/textured paint

Please Contact Us to Order to offer best price and delivery time for Sauter - 118004 / Typ:0.5.450.416 12-way tool disk revolver number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
