| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2P4942FSRA |
| Internal code | ONR4863918 |
| Technical specification | Size 2 external gear pump with aluminum body and aluminum flanges Delivery volume: 14.4 ccm/U Direction of rotation: clockwise Mounting flange: single-pass Ø 80 mm - 4 hole mounting 100mm x 72 mm - Ø 9 mm Drive shaft: conical 1:5 - disc spring 3 mm Suction connection: LK 40 mm BOSCH - M6 x 1 Pressure connection: LK 35 mm BOSCH - M6 x 1 Installation length: 104.2 mm Sealing material: NBR Allowable shaft torque: 233.2 Nm Continuous pressure limited by drive shaft: 250 bar Continuous pressure: 250 bar Peak pressure (max. 0.5 sec.): 290 bar Minimum speed: 700 rpm Maximum speed: 3500 rpm |
Please Contact Us to Order to offer best price and delivery time for Vivoil Oleodinamica Vivolo - X2P4942FSRA number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Vivoil Oleodinamica Vivolo - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy X2P4942FSRA by Vivoil Oleodinamica Vivolo in United States?
You can purchase X2P4942FSRA by Vivoil Oleodinamica Vivolo from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the X2P4942FSRA?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Vivoil Oleodinamica Vivolo in United States?
While we are not the official distributor or seller of Vivoil Oleodinamica Vivolo in United States, we source our products from reliable channels and offer you original Vivoil Oleodinamica Vivolo equipment at competitive prices.
How can I access X2P4942FSRA catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for X2P4942FSRA on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for X2P4942FSRA?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
XV1P / 3,8D-3 / 8-3 / 8 3,64ccm / U - clockwise - 250bar 71,9x52,4mm - ø25.4 - conically 1: 8 - F 3/8 "-3/8" BSP 010 Gear pump XV
X1P2344DZZB XV1P / 3.2D-BH-Ø32 OUT CF.002-Z-Z-IN3 / 8 3,12ccm / U - clockwise - 250bar 40x40mm - Ø32 - protruding tongue shaft 5mm - suction inlet rear 3/8 "BSP - pressure front output
X2P4702EOO to XV2P / 11D NEW MODEL
16,8ccm / U - counterclockwise - 230bar 96,2x71,5mm - Ø36,5 - conically 1: 8 - LK40 / 30 010 Gear pump XV
Gear pump
010-250-02100 / X2P6302EDCA / XV2P/40D-1-3/4
(39,6ccm / U - clockwise - 140bar 96,2x71,5mm - Ø36,5 - conically 1: 8 - IG 1 "-3/4" BSP, 010 Gear pump XV)
XV1P / 3,8D-ø25.4-CO.001-LB 3,64ccm / U - clockwise - 250bar 71,9x52,4mm - Ø 25.4 - conically 1: 8 - LK30 / 30 German 012 Gear pump XVD
(XV2P / 4D Ø82,5-SAEA-CI.002 4,2ccm / U - clockwise - 260bar 2 hole 106,4mm - Ø82,5 - SAEA - cylindrical Ø15,875 - LK40 / 35 German 012 Gear pump XVD)
54,60ccm-clockwise-230bar 128,1x98,4mm - Ø50,8 - Tapered 1: 8 - LK51 014 Gear pump XV3
externally XV2M / 11-30 / 30-leaking oil 1 40 10,8ccm / U - reversing - 260bar 96,2x71,5mm - Ø 36.5 - Conical 1: 8 - external LK30 / 30 Euro-Leakage - For applications of these engines in Series circuits, please hold first talking to our technical department 016 Gear motors XV
9RS04D21 RV-1S/2,6x4 EAV 70-210 bar p max: 220bar - Eingang 2x1/2" IG
021-010-14400 (9RV02A29 RV-1V/4,9X2 EAV 7-210 BAR)
(P max: 220bar - Input 1x1 / 2 "IG 2 times gear flow divider with Endlagenausgleichs- and suction valves - Guidelines for the design and flow dividers on our website absolutely starting up! 021-gear flow divider RV Italy Weight approx 2.4kg Customs tariff number: 84 12 29 81)
2 times gear flow divider without valves
9RD0347 RV 2D / 11x3 p max: 210bar - Eing.1x3 / 4 "- Ausg.3x1 / 2"
X1T2501FIIA XV1T / 3.8 sec-30/30 3,64ccm / U - counterclockwise - 250bar Front section - 71,9x52,4 - Ø 25.4 - Conical 1: 8 - LK30 / 30 € 022 Gear pump stages XV
X1T2501FBBA XV1T / 3.8 sec-3 / 8-3 / 8 3,64ccm / U - counterclockwise - 250bar Front section - 71,9x52,4 - ø25.4 - conically 1: 8 - F 3/8 "-3/8" BSP 022 Gear pump stages XV
X1T3402FBBA, XV1T / 7,8D-3 / 8-3 / 8, 7,54ccm / U - clockwise - 220bar, front section - 71,9x52,4 - ø25.4 - conically 1: 8 - F 3/8 "-3 / 8 "BSP, 022 gear pump stages XV
Sealing set-XV2P-complete-NBR 1 40 Gear pump XV2P-Ø36,5 + 50 + 80 + 82.5
Shaft sealing ring
Pressdichtung-XV2 (NBR 70 SH)
Support ring XV2 internally
Support ring XV2-externally
Driven wheel XV2 conically 1 ÷ 8 CO001
driven wheel XV2 with hole
Brille-KV2P I=31.4 H=20 +2DU
Disc spring KV2P-KV2M ø16x4-H = 6.5 7 40 for shaft CO.001 - 1: 8
[028-320-01550 Brille-XV2 I = 31.4 H = 20 + 2DU]
028-390-01750, coupling sleeve XV-3P + 2P - L = 28 - 25x22 + 17x14
