| BRAND | Stahl |
| Product | 162211 / 9440/22-01-21-C1243 |
| Description | Remote I/O IS1 CPU and power module for Zone 1 |
| Internal code | ONR5081615 |
| Custom code | 85363010 |
Please Contact Us to Order to offer best price and delivery time for Stahl - 162211 / 9440/22-01-21-C1243 Remote I/O IS1 CPU and power module for Zone 1 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Stahl - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 162211 / 9440/22-01-21-C1243 by Stahl in United States?
You can purchase 162211 / 9440/22-01-21-C1243 by Stahl from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 162211 / 9440/22-01-21-C1243?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stahl in United States?
While we are not the official distributor or seller of Stahl in United States, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.
How can I access 162211 / 9440/22-01-21-C1243 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 162211 / 9440/22-01-21-C1243 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 162211 / 9440/22-01-21-C1243?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
8118/122-199 Terminal box Ex e
junction box; Protection: IP66; Inputs: 1 X M25, 4 X M20; Body material: SS; Cover material: SS; Sizes: 236mm x 176mm x 91mm COMPLETE with terminals for 2.5 mm2 WIRES
8146/5052-C796 alarm and fire alarm with mushroom put button
control box Type: 8146/5041 Technical specifications: Gas - Explosion protection: Ex II 2 G Ex de IIC T6 Gb Dust - Explosion protection: Ex II 2 D Ex tb IIIC T80 ° C Db IP66 Test Certificate ATEX: PTB 01 ATEX 1024 Test certificate IECEX: IECEx PTB 06.0090 Material: Polyester resin Dimensions: 112 x 170 x 91 mm IP 66 Ambient temperature: -20 ° C ... + 40 ° C Rated voltage: 230 V / 50 Hz Rated current: 6 A Control voltage: V / Hz Schematic: Without wiring Other Approval: on request 1 ST Pilzschluesseltaster EMERGENCY STOP MS 1 Contact element Oe + S 1 ST protective conductor terminal USLKG 5 1 ST: Lower 8161/5 M20-13-fitting M20x1,5sw
137051 / 8146/1051 TERMINAL BOX EX E
Technical data: Gas - Explosion protection: Ex II 2 G Ex e II T6 Dust - Explosion protection: Ex II 2 D Ex tD A21 IP66 T 80 °C Certificate ATEX: PTB 01 ATEX 1016 Certificate IECEx: IECEx PTB 06.0046 Material: Polyester resin Dimension: 170 x 170 x 91 mm Degree of protection: IP 66 Ambient temperature: - 40°C ... + 40°C Rated voltage: 550 V Cross section: 2.5 mm² Also certified to: on request Fitting position: side D bottom, rail horizontal 12 pc(s) line-up terminal WDU 2,5/E labelling: 1-12 1 pc(s) TS35 mounting rail TS35 in enclosure 8146 for terminals length: 133mm 1 pc(s) 8146 PE-Rail 7x4 mm² gn-ye 1 pc(s) Side: bottom 8161/5-M25-17 cable gland M25x1,5 black 1 pc(s) Side: left 8161/5-M25-17 cable gland M25x1,5 black 3 pc(s) Side: left 8161/5-M16-10 cable gland M16x1,5 black 1 pc(s) Side: right 8161/5-M25-17 cable gland M25x1,5 black 3 pc(s) Side: right 8161/5-M16-10 cable gland M16x1,5 black CCT No.: 85369085 DE Net weigth: 0,770 KG
Blanking Plug
138382 BLANKING PLUGS F. CABLE GLANDS M25.....25PCS
.CCT No.: 39269097 DE Net weigth: 0,130 KG
(nut M16 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M16 x 1.5 Width across flats [mm]: 19 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,135 KG)
138383 NUT M16 BRASS NICKEL PLATED 50PCS
.Locknut, metric brass, nickel plated Internal thread d: M16 x 1.5 Width across flats [mm]: 19 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,135 KG
nut M20x1.5
Blanking Plug
(nut M25 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M25 x 1.5 Width across flats [mm]: 29 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,348 KG)
138395 NUT M25 BRASS NICKEL PLATED 50PCS
.Locknut, metric brass, nickel plated Internal thread d: M25 x 1.5 Width across flats [mm]: 29 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,348 KG
(blanking plugs f. cable glands Pg9 /M16.....50pcs CCT No.: 39269097 DE Net weigth: 0,061 KG)
138406 BLANKING PLUGS F. CABLE GLANDS PG9 /M16.....50PCS
.CCT No.: 74153300 IN Net weigth: 0,061 KG
(blanking plugs f. multiple cable glands, d 5,5mm...50pcs CCT No.: 39269097 DE Net weigth: 0,031 KG)
Cable gland with reduction sealing insert explosion-protected
.Cable gland Ex e polyamide, 4x4-6mm, 50 pcs Cable Glands Series 8161, explosion protected Version: 8161/5 Ex e (black) Thread size: M25 x 1.5 Number of entries: 4 Cable dia. range [mm]: 4 ... 6 For use in: Zones 1 & 2, 21 & 22 CCT No.: 39269097 DE Net weigth: 1,000 KG
8161/5-M16-9 Cable gland Ex e polyamide, 4-9mm, 50 pcs Cable Glands Series 8161, explosion protected Version: 8161/5 Ex e (black) Thread size: M16 x 1.5 Number of entries: 1 Cable dia. range [mm]: 4 ... 9 For use in: Zones 1 & 2, 21 & 22
(Cable Glandsexplosion-protectedType : 8161/5-M25-17Thread size : M25Thread length : 10 mmMaterial : PolyamideColour : blackClamping range : 7 ... 17 mm2Cable armour : Unarmoured cablesApplication range (Zone) : 1 , 2 , 21 , 22Type of protection (IP) : IP66Gas explosion protection : II 2 G Ex e IIDust explosion protection : II 2 D Ex tD A21Min. ambient temperature : -40 °CMax. ambient temperature : +75 °CCCT No.: 39269097 DENet weigth: 0,020 KG)
138772 8163/2-20-A2F-M20 CABLE GLAND
.Cable Glands Ex d and Ex e for Unarmoured Cables Series 8163/2-A2F, explosion protected Thread size C: M20 x 1.5 Cable diameter A: min.6.5 max.14.0 PVC-shroud: HV 05 Version: BS 6121, EN 50262 For use in: Zones 1 & 2, 21 & 22 CCT No.: 85369010 GB Net weigth: 0,070 KG
143524 8290/3-M25 STOPPING PLUG M25X1,5
.Stopping Plugs Series 8290, explosion protected Thread size: M25 x 1.5 Material: Polyamide Colour: black For use in: Zones 1 & 2, 21 & 22 CCT No.: 39269097 DE Net weigth: 0,007 KG
(Stopping Plug explosion-protected Type : 8290/3-M25 Material : Polyamide Thread size : M25 Drive : Hexagon socket Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e IIC Gb Dust explosion protection : II 2 D Ex tb IIIC Db Min. ambient temperature : -60 °C Max. ambient temperature : +80 °C Packaging unit : 100 CCT No.: 85389099 DE Net weigth: 0,700 KG)
143554 8290/3-M16 STOPPING PLUG M16X1,5
.Stopping Plugs Series 8290, explosion protected Thread size: M16 x 1.5 Material: Polyamide Colour: black For use in: Zones 1 & 2, 21 & 22 CCT No.: 85389099 DE Net weigth: 0,003 KG
(Stopping Plug explosion-protected Type : 8290/3-M16 Material : Polyamide Thread size : M16 Drive : Hexagon socket Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e IIC Gb Dust explosion protection : II 2 D Ex tb IIIC Db Min. ambient temperature : -60 °C Max. ambient temperature : +80 °C Packaging unit : 100 CCT No.: 85389099 DE Net weigth: 0,300 KG)
143707 REDUCTION EXPLOSION-PROTECTED TYPE : 8295/1R1-M25X1,5 M20X1,5
.External thread : M25 x 1.5 Internal thread : M20 x 1.5 Wrench size : A/F32 Material : Steel galvanized Version : Metric / Metric Application range (Zone) : 1 , 2 Gas explosion protection : II 2 G Ex e II Min. ambient temperature : -55 °C Max. ambient temperature : +130 °C Certificate IECEX Gas : IECEx PTB 06.0075U Certificate ATEX Gas : PTB 02 ATEX 1067 U For further information, see : www.r-stahl.com Web code 8295A Adaptors Metric / Metric, galvanized steel, explosion protected External thread d1: M25 x 1.5 Internal thread d2: M20 x 1.5 Width across flats [mm]: 32 CCT No.: 73181900 DE Net weigth: 0,073 KG
8491 / 11-230 horn with horn 230V, AC
8491 / 21-230 Flachhupe 230V, AC
8570/12-306 Plug 2P+PE 16A 200-250V, 60+60Hz, 6h, blue
